| Efficiency |
|
| Max.efficiency |
98.6% |
| European efficiency |
98.1% |
| Input(PV) |
|
| Recommended max. PV power 1 |
15,000 Wp |
| Max. input voltage2 |
1,100V |
| Operating voltage range 3 |
140 V ~ 980 V |
| Start-up voltage |
200 V |
| Rated input voltage |
600 V |
| Max. input current per MPPT |
11 A |
| Max. short-circuit current |
15 A |
| Number of MPP trackers |
2 |
| Max. input number per MPP tracker |
1 |
| Input (DC Battery) |
|
| Compatible Battery |
HUAWEI Smart String ESS 5kWh – 30kWh |
| Operating voltage range |
600 V ~ 980 V |
| Max operating current |
16.7 A |
| Max charge Power |
10,000 W |
| Max discharge Power |
10,000 W |
| Output(On Grid) |
|
| Grid connection |
Three-phase |
| Rated output power |
10,000 W |
| Max. apparent power |
11,000 VA 4 |
| Rated Output Voltage |
220 Vac / 380 Vac, 230 Vac / 400 Vac, 3W / N+PE |
| Rated AC Grid Frequency |
50 Hz / 60 Hz |
| Max. Output Current |
16.9 A |
| Adjustable Power Factor Range |
0.8 leading... 0.8 lagging |
| Max. Total Harmonic Distortion |
≤ 3 % |
| Output(Off Grid) |
|
| Backup Box |
Backup Box B-1 |
| Maximum apparent power |
3,300 VA |
| Rated output voltage |
220 V / 230 V |
| Maximum output current |
15 A |
| Power factor range |
0.8 leading ... 0.8 lagging |
| Features & Protection |
|
| Input-side Disconnection Device |
Yes |
| Anti-islanding Protection |
Yes |
| DC Reverse-polarity Protection |
Yes |
| Insulation monitoring |
Yes |
| DC surge protection |
Yes, compatible with TYPE II protection class according to EN/IEC 61643-11 |
| AC surge protection |
Yes, compatible with TYPE II protection class according to EN/IEC 61643-11 |
| Residual current monitoring |
Yes |
| AC Overcurrent Protection |
Yes |
| AC short-circuit protection |
Yes |
| AC overvoltage protection |
Yes |
| Arc fault protection |
Yes |
| Ripple receiver control |
Yes |
| Integrated PID recovery5 |
Yes |
| Battery reverse charging from grid |
Yes |
| General Data |
|
| Operating temperature range |
-25 ~ + 60 °C (-13 °F ~ 140 °F) |
| Relative operating humidity |
0 %RH～ 100 %RH |
| Max. operating altitude |
4,000 m (13,123 ft.) (Derating above 2000 m) |
| Cooling |
Natural convection |
| Display |
LED Indicators; Integrated WLAN + FusionSolar App |
| Communication |
RS485; WLAN/Ethernet via Smart Dongle-WLAN-FE; 4G / 3G / 2G via Smart Dongle-4G (Optional) |
| Weight (incl. mounting bracket) |
17 kg (37.5 lb) |
| Dimension (incl. mounting bracket) |
525 x 470 x 146.5 mm (20.7 x 18.5 x 5.8 inch) |
| Degree of protection |
IP65 |
| Nighttime Power Consumption |
< 5.5 W 6 |
| Optimizer Compatibility |
|
| DC MBUS compatible optimizer |
SUN2000-450W-P |
| Standard Compliance (more available upon request) |
|
| Certificate |
EN/IEC 62109-1, EN/IEC 62109-2, IEC 62116 |
| Grid Connection Standards |
G98, G99, EN 50438, CEI 0-21, VDE-AR-N-4105, AS 4777, C10/11, ABNT, UTE C15-712, RD 1699, TOR D4, NRS 097-2-1,
IEC61727, IEC62116, DEWA |
